Technical Specifications
System
CPU :
Intel® Icore i7 8700
Cache :
12 mb
Memory :
1 x DDR4 SoDIMM 16 GB 2400MHZ
Video RAM :
Intel® UHD 630 Graphics
Chipset :
Intel® H310
System Fan :
Slim Radial Fan
I/O
Capture Card :
HDMI Analog Svideo
Serial Port :
(1 x RS-232/422/485, 1 x RS-232)
Parallel Port :
N.A
USB Port :
4 x USB 2.0 , 4 x USB 3.0
KB / MS :
N.A.
LAN :
2 x LAN Intel® I217V Ethernet
Keyboard :
Integrated Antibacterial Turkish Keyboard
Mouse :
Integrated Antibacterial Mouse
Wireless LAN :
802.11 b / g / AC
Audio :
Line in & out (AC’97 codec audio)
Expansion Slot :
PCIe / MiniPCIe
Data Storage
HDD / Type :
Vibration Resistant Slot 2.5” (2 TB HDD)
SSD :
256 GB
Feed
Input :
220VAC
Extra Video Output
Type :
2xDP/1xVGA/HDMI
Max. Resolution :
VGA/HDMI(1920x1080) , DP(4096X2304)
LCD Screen
Type and Size :
24" / 16:9
Max. Resolution :
1920x1200
Pixel Pitch :
0.270mm x 0.270mm
Max Color :
1.07M
Brightness (cd/m2) :
900 nits
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 hours
Touch Screen :
N.A
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Custom Built-in Glass
Weight :
Variable according to screen size
Dimensions :
Variable by screen size
Mounting :
Built-on
Output
Screen Outputs :
2 x SDI In/Out 1 x DP 2 x DVI 1 x VGA S-Video In/Out CVBS In/Out YPbPr / XsRGB In/Out
Order Code
CPU :
İ7 8700
PSU :
AC220
Optical Drive :
DVD-RW
RAM :
R16
HDD :
2TB HDD / SSD256
Wifi :
802.11 b / g / AC
DICOM Viewer :
DICOM Preset
RFID Reader :
N.A
Barcode Reader :
N.A
