K-410-AND-MCD Series

Artech Mini Smart Kiosk: Contactless Access Control and Smart ID Reading Solution

Artech Mini Smart Kiosk can read and register new type smart ID cards and control access through turnstiles and doors. For contactless access, it manages access control with its built-in QR/barcode reader, scanning QR codes from mobile phones or reading Mifare-type contactless cards. With its modern look, high-resolution 10.1'' wide screen, and Android operating system, you can create an effective and dynamic communication network. The local content management software provides your target audience with real-time information flow. The IP65 front protection allows the touchscreen to be easily disinfected, enabling you to conduct electronic surveys and strengthen your brand communication.

Key Features:

  • Smart ID Card Reading: Reads and registers new type smart ID cards.
  • Contactless Access Control: Built-in QR/barcode reader scans from mobile phones or contactless cards.
  • 10.1'' Wide Screen: High-resolution, modern design.
  • Android Operating System: Dynamic communication with content management software.
  • IP65 Front Protection: Disinfectable touchscreen.
Interactive Design
Interactive Design
Wide Touch Screen
Wide Touch Screen
IP65 Front Panel Protection
IP65 Front Panel Protection
Industrial Stainless Steel Body
Industrial Stainless Steel Body
Bright and High Contrast TFT LCD Screen
Bright and High Contrast TFT LCD Screen
Wide Viewing Angle
Wide Viewing Angle

Sectors

Technical Specifications

System
CPU :
4 Core 1.5GHZ
Cache :
By CPU
Memory :
2GB 1600MHZ
Video RAM :
N.A.
System Fan :
N.A.
I/O
LAN :
10/100/1000 Mps POE Ethernet
Wireless LAN :
N.A.
Audio :
Internal Speaker
Data Storage
Memory :
16GB-eMMC
HDD / Type :
eMMC
Feed
UPS :
10.000 mAh Lithium Iyon
LCD Screen
Reaction Time :
8 MS
Type and Size :
10” LVDS (16:9 Wide Screen)
Max. Resolution :
1280 x 800 Pixel
Pixel Pitch :
0.297(H) x 0.297(W)
Max Color :
16.7 M
Brightness (cd/m2) :
300 Nits
Contrast Ratio :
1300/1
Viewing Angle :
178°(H),178°(V)
Back Light MTBF :
50,000 Hours
Touch Screen :
10" Touch - Capacitive
Smart Card Reader
Read Property :
ISO 7816 Class A,B,C Card Reading Standard
NFC Card Reader
Tag Reader :
13.56 MHZ
Reading Rate :
106 Kbit/sn
QR Code Reader
Scanning Rate :
300 frames / sec.
Reading Format :
PDF 417, GM, QR Code,DataMatrix, AZTEC, Hanxin Code, Maxicode, Micro QR, Micro PDF417, Code One Standard
Camera :
1280X800 CMOS Sensor
Connection Style :
USB
Mechanical & Environmental Specifications
IP Class :
IP65 in Front / IP54 in Backside
Operating Temperature :
-10 ~ +50°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Durable Stainless Metal Case
Weight :
Variable by Screen (1-5 kg)
Dimensions :
Variable by Screen
Mounting :
Surface Mounted - 100x100mm Surface Mounted Hanging Apparatus
Order Code
Feed :
10.000mAh Lithium Iyon
Reader/Printer :
NFC Card Reader / QRCode Reader / Smart Card Reader
Operating System :
Android 6.0
CPU :
4 Core 1.5 GHZ
RAM :
2GB 1600MHZ
HDD :
16GB-eMMC
Wifi :
N.A

Support

Please contact us for information about the products or for technical support.
