Technical Specifications
System
Cache :
2nd Level depends on CPU
Memory :
4GB
Video RAM :
Max 128 MB shared memory
Chipset :
Intel® Soc / QM77
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
Android OS :
Android 8.0
Processor :
4x ARM Cortex-A17 @ 1.61 GHz
I/O
Serial Port :
N.A.
USB Port :
2 x USB 2.0
LAN :
1 x LAN Realtek Gigabit Ethernet
Audio :
3W Stereo Output / 5W Speaker (Optional)
Data Storage
Memory :
2GB
EEMC :
16GB Flash
SSD :
64 GB
Feed
Input :
220VAC
Extra Video Output
Type :
HDMI/DP/DVI/VGA Optional)
Max. Resolution :
1920x1080(2560x1600 Optional)
LCD Screen
Type and Size :
65" LVDS
Max. Resolution :
1920x1080
Pixel Pitch :
0.744mm x 0.744mm
Max Color :
16.7 M
Brightness (cd/m2) :
450cd
Contrast Ratio :
1000/1
Viewing Angle :
178°(H),178°(V)
Back Light MTBF :
50,000 hours
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty
Front Frame :
Metal Case HDD / Type Vibration Resistant Slot 2.5 ”(500 GB HDD) Front Frame Metal Frame / Glass (Optional)
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Surface Mount / Built-in
Order Code
CPU :
4x ARM Cortex-A17 @ 1.61 GHz
PSU :
AC - 220VAC
RAM :
R4
HDD :
HDD 500GB(OPS), SSD64
Wifi :
N.A
