Technical Specifications
Video Input
Type :
HDMI/VGA
LCD Screen
Type and Size :
15,6” LVDS (16:9 Widescreen)
Max. Resolution :
1920 x 1080
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
350cd
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 Hours
Touch Screen :
15,6" Touch - Projected Capacitive
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Metal
Front Frame :
IP65
Weight :
Variable According to the Screen Size (1 - 5 kg)
Mounting :
Panel and Vesa
Order Code
PSU :
DC - 12/24 VDC
