M-716 Series

Artech Industrial Monitor: Durable Solution for Digital Signage and Corporate Communication

The Artech Industrial Monitor is a 15.6'' industrial-grade compact LCD display solution, designed specifically for digital signage and corporate communication applications. Engineered to operate flawlessly in harsh industrial environments, this monitor offers maximum durability with its IP65-rated front panel protection and industrial stainless steel body. The power supply filter reduces problems that may arise from electrical noise, ensuring stable operation.

Key Features:

  • 15.6'' Industrial Monitor: Compact size suitable for a variety of industrial applications.
  • IP65 Front Panel Protection: Offers high-level protection against dust and water.
  • Industrial Stainless Steel Body: Ensures longevity and robust structure.
  • Power Supply Filter: Increases system stability and minimizes electrical noise.

The Artech Industrial Monitor is ideal for professionals seeking high performance and reliability in applications such as factory automation, control rooms, and public area digital signage.

Power Supply Filter
Power Supply Filter
IP65 Front Panel Protection
IP65 Front Panel Protection
Industrial Stainless Steel Body
Industrial Stainless Steel Body

Sectors

Technical Specifications

Video Input
Type :
HDMI/VGA
LCD Screen
Type and Size :
15,6” LVDS (16:9 Widescreen)
Max. Resolution :
1920 x 1080
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
350cd
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 Hours
Touch Screen :
15,6" Touch - Projected Capacitive
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Metal
Front Frame :
IP65
Weight :
Variable According to the Screen Size (1 - 5 kg)
Mounting :
Panel and Vesa
Order Code
PSU :
DC - 12/24 VDC

Support

Please contact us for information about the products or for technical support.
