Technical Specifications
System
CPU :
Intel® N4200 / i3 / i5 / i7
Cache :
By CPU
Memory :
2 x DDR3 SO-DIMM Sockets, Max. Capacity 32 GB
Video RAM :
Intel® HD Graphics
Chipset :
By CPU
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
I/O
Serial Port :
RS-232/422/485
Parallel Port :
N.A.
USB Port :
4 x USB 3.0
LAN :
Dual LAN; Dual Gigabit Ethernet 10/100/1000
Wireless LAN :
802.11 b / g / n (Optional)
Audio :
Line In & Out (AC’97 codec audio)
Data Storage
HDD / Type :
2.5 ”HDD in Vibration Resistant Slot
SSD :
64 GB / 128 GB / 256 GB
Feed
Input :
110 / 220VAC or / 24VDC
Extra Video Output
Type :
HDMI/VGA
Max. Resolution :
4096x2160
LCD Screen
Type and Size :
15,6” LVDS (16:9 Widescreen)
Max. Resolution :
1366 x 768
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
350cd
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 Hours
Touch Screen :
15,6" Touch - Projected Capacitive
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Metal
Front Frame :
IP65
Weight :
Variable According to the Screen Size (1 - 5 kg)
Mounting :
Panel and Vesa Mounting
Order Code
CPU :
N4200, i7, i5, i3
PSU :
DC - 12/24 VDC
RAM :
R4, R8, R16, R32
HDD :
500 GB HDD(Optional), 64 GB SSD, 128 GB SSD, 256 GB SSD
Wifi :
Optional
