Technical Specifications
System
CPU :
Intel® Core i7 / i5
Cache :
By CPU
Memory :
4GB / 8GB
Video RAM :
Max 128 MB shared memory
Chipset :
Intel® / QM77
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
I/O
Serial Port :
N.A.
Parallel Port :
N.A.
USB Port :
2 x USB 2.0 compliant
LAN :
1 x Gigabit Ethernet (Ops 2 x Gigabit Ethernet)
Wireless LAN :
Opsiyonel - 802.11 b / g
Audio :
2x10W Stereo Speaker
Data Storage
HDD / Type :
2.5” (500 GB HDD)
SSD :
64 GB / 128GB / 256 GB
Extra Video Output
Type :
Optional—VGA / DVI / HDMI
Max. Resolution :
1920x1080
LCD Screen
Type and Size :
43" LVDS
Max. Resolution :
1920x1080
Pixel Pitch :
0.4902 mm x 0.4902 mm
Max Color :
16.7 M
Brightness (cd/m2) :
450 cd
Contrast Ratio :
1000/1
Viewing Angle :
178°(H),178°(V)
Back Light MTBF :
50,000 hours
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
10 ~ 90% (non-condensing)
Case :
Heavy-Duty Metal Case
Weight :
Variable according to screen size
Dimensions :
Variable according to screen size
Mounting :
Mobile/Ground Fixed - Optional
Touch :
Optional
Order Code
CPU :
i5, i7
PSU :
AC - 220VAC
RAM :
R4, R8, R16
HDD :
500GB HDD(OPS), SSD64, SSD128, SSD256
Wifi :
Opsiyonel
