Technical Specifications
System
CPU :
RK3566 - SoC Quad-core, up to 2.0 GHz - Fanless
Memory :
2GB
Watchdog Timer :
Support
Android OS :
Android 11.0
Memory :
8GB
I/O
USB Port :
2x USB 2.0
LAN :
RJ45 10M/100M
Audio :
Stereo L/R phone jack and 10 W / 8Rx2
Data Storage
EEMC :
8GB
LCD Screen
Type and Size :
55" TFT LCD
Max. Resolution :
1920 x 1080 Pixels
Pixel Pitch :
0.630(H) x 0.630(W)
Max Color :
16.7M
Brightness (cd/m2) :
2500cd
Contrast Ratio :
5000/1
Viewing Angle :
178°(H),178°(V)
Back Light MTBF :
50,000 hrs
Touch Screen :
N.A
Screen :
1
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
10 ~ 90% (non-condensing)
Case :
Heavy Duty Metal Case
Weight :
Variable According to the Screen Size
Dimensions :
707mm x 1772mm x 150mm
Mounting :
Fixing to the Ground
Order Code
CPU :
RK3566 - SoC Quad-core, up to 2.0 GHz - Fanless
PSU :
220V
RAM :
2GB
HDD :
16GB (Flash)
