Technical Specifications
System
CPU :
Intel® Icore i5/i7
Cache :
By CPU
Memory :
2x DDR4 2133 MHz / 32GB Max
Video RAM :
Intel Gen9 Graphics
Control :
Intel® H110
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
I/O
Serial Port :
2 x RS-232/422/485
USB Port :
2 x USB 2.0 - 1 x PS2 K/B and Mouse
LAN :
1 x LAN Realtek Gigabit Ethernet
Audio :
Line in & out (AC’97 codec audio)
Expansion Slot :
1 x PCIex16, 1xPCIe x1, 3xPCI, 1xPCIe x4, 1xMsata
Data Storage
Memory :
Vibration Resistant Slot 2.5 ”(500 GB HDD)
SSD :
1TB
Feed
Input :
110 / 220VAC
Extra Video Output
Type :
HDMI
Max. Resolution :
1920x1080
LCD Screen
Type and Size :
55" LVDS
Max. Resolution :
1920x1080
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
500/700cd
Contrast Ratio :
700/1
Viewing Angle :
178°(H),178°(V)
Back Light MTBF :
50,000 hours
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Metal Frame
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Panel / Wall Mount
Order Code
CPU :
i5, i7
PSU :
AC - 220VAC
RAM :
R4, R8, R16
HDD :
1 TB
Wifi :
N.A
